Tilt Trim Motor Compatible With Mercury Mariner 75Hp 90Hp 100Hp 115Hp 135Hp 150Hp 175Hp 200Hp

OEM PART NUMBERS:
• Mercury Marine: 811628
• Mercury Marine: 828708A1
• Mercury Marine: 878265A2
• Mercury Marine: 878265A6
• Mercury Marine: 85974



AFTERMARKET CROSS REFERENCE:
• API Marine: PT485NMK-3
• Arco Marine: 6279
• 18-6774
SPECIFICATIONS:
• Type: Tilt Trim Motor (Motor Only — No Pump)
• Voltage: 12V DC
• Rotation: Reversible
• Connection: 3-Wire
• Terminals: 1/4 Inch Ring Terminal (x3)
• Shaft OD: 7.4mm / 0.291in
• Shaft Type: Blade
• Field Housing OD: 78.1mm / 3.075in
• Overall Length: 138.4mm / 5.449in
• Mount: 2-Bolt / Flat Blade Coupler
• System: Design II, 3-Ram, Aft Fill Integral Trim/Tilt
• Replaces: Square Eaton Style Motor
• Weight: 5.95 lbs / 2.70 kg
• Condition: New

MERCURY / MARINER APPLICATIONS:
• 3-Cyl: 75-90HP (1990-1993)
• 4-Cyl: 100-125HP (1988-1995)
• V6: 135-225HP (1992-1998)
• EFI Pro Max/Super Mag: 150-225HP (1994-1997)
• Jet: 105-140HP (1992-1996)
• Magnum II 2.5L V6 (1990-1991)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
MERCURY 3-CYLINDER OUTBOARD:
• 75HP 3-Cyl 2-Stroke (1990-1993)
• 90HP 3-Cyl 2-Stroke (1990-1993)

MERCURY 4-CYLINDER OUTBOARD:
• 100HP 4-Cyl 2-Stroke (1988-1993)
• 115HP 4-Cyl 2-Stroke (1988-1993)
• 120HP (1995)
• 125HP (1994-1995)

MERCURY V6 OUTBOARD:
• 135HP V6 2-Stroke (1992-1995)
• 150HP V6 2-Stroke (1992-1995)
• 175HP V6 2-Stroke (1992-1995)
• 200HP V6 2-Stroke (1992-1995)

MERCURY V6 3.0L / EFI / HIGH PERFORMANCE:
• 225HP 3.0L V6 Carb (1994-1998)
• 225HP Marathon 3.0L V6 Carb (1994-1998)
• 225HP SeaPro 3.0L V6 Carb (1994-1998)
• 225HP EFI Pro Max / Super Mag V6 (1995-1997)
• 150HP EFI Pro Max / Super Mag V6 (1994-1997)
• 200HP EFI Pro Max / Super Mag V6 (1994-1997)
• Magnum II 2.5L V6 2-Stroke (1990-1991)

MERCURY JET OUTBOARD:
• 105 Jet 6-Cyl 2-Stroke (1993-1996)
• 140 Jet 6-Cyl 2-Stroke (1992-1995)

MARINER OUTBOARD:
• All Mariner 75-225HP Models with Design II 3-Ram Aft Fill System

ADDITIONAL MERCURY/MARINER APPLICATIONS:
• 35HP (1992-1995) / 40HP (1992-1995)
• 50HP (1992-1995) / 60HP (1992-1995) / 70HP (1992-1995)

SYSTEM TYPE:
• Design II, 3-Ram, Aft Fill Integral Trim/Tilt System
• Square Eaton Style Motor Replacement
