Spindle Assembly Compatible With Exmark Lazer Z Xp As Lc 52 60 72 Inch Deck Zero Turn Mower 103-3206

OEM PART NUMBERS:
• Exmark: 103-8075 / 1038075 (current)
• Exmark: 103-3200 / 1033200 (superseded)
• Exmark: 103-3206 / 1033206
• Exmark: 103-8323 / 1038323

SPECIFICATIONS:
• Type: Complete Cutter Housing Assembly (Spindle Assembly)
• Overall Height: 6-1/2"
• Housing Outer Diameter: 5-1/2"
• Pulley Outer Diameter: 6-1/2"
• Bolt: 5/8"-18 x 1-3/8"
• Includes: Pulley, Pulley Nut, Cup Washers, Bolt, Dust Cover, Relief Valve, Grease Zerk
• Condition: New

APPLICATION:
• Exmark Lazer Z AC/AS/LC/XP/XS 52"/60"/72" Deck
• Exmark Lazer Z Diesel 60"/72" Deck
• Exmark Turf Tracer 52"/60" Deck
• Exmark Turf Ranger 52" Deck
• Exmark Front Mount FMD524/FMD604
• May be outer spindle only on some models — verify with parts diagram

Spindle Assembly - Exmark Lazer Z and Turf Series Commercial Mowers
Direct OEM replacement spindle assembly for Exmark commercial mowers with 52-inch, 60-inch, and 72-inch decks. Housing stands 6-1/2 inches tall with 5-1/2 inch OD and 6-1/2 inch pulley. Complete assembly includes pulley, nut, cup washers, bolt, dust cover, relief valve, and grease zerk. Replaces Exmark 103-8075, 103-3200, 103-3206, and 103-8323.PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
EXMARK LAZER Z ZERO TURN MOWERS (52"/60"/72" DECK):
• LZ20KC524 / LZ20KC524AS Lazer Z 52" Deck
• LZ23KC524AS Lazer Z XP 52" Deck
• LZ23KC604 / LZ23KC604AS Lazer Z 60" Deck
• LZ25KC524 Lazer Z 52" Deck
• LZ25KC604 / LZ25KC604AS Lazer Z 60" Deck
• LZ26KC604 Lazer Z XS 60" Deck
• LZ27DD604 Lazer Z Diesel 60" Deck
• LZ27KC524 Lazer Z 52" Deck
• LZ27KC604 Lazer Z 60" Deck
• LZ27LKA604 Lazer Z XS 60" Deck
• LZ28KC604 Lazer Z 60" Deck
• LZ31BV604 Lazer Z 60" Deck
• LZ31DG604 Lazer Z Diesel 60" Deck
• LZ31DG724 Lazer Z Diesel 72" Deck

EXMARK TURF TRACER WALK-BEHIND MOWERS (52"/60" DECK):
• TT20KC / TT20KCC 52" and 60" Deck
• TT23KAC / TT23KCC 52" and 60" Deck

EXMARK TURF RANGER MOWERS (52" DECK):
• TR23KC / TR23KC524 52" Deck

EXMARK FRONT MOUNT DECK:
• FMD524 52" Deck
• FMD604 60" Deck

FITMENT NOTES:
• Compatible with Lazer Z AC, AS, LC, XP, and XS series
• May be outer spindle only on some models — verify with parts diagram for your serial number
• Serial number range may affect fitment — check your specific model

NOTE: Verify OEM part number from your original unit before ordering to ensure proper fitment.
