New Turbocharger Compatible With John Deere 7700 Forage Harvester (Self-Propelled) By Part Numbers

PRODUCT TYPE: TURBOCHARGER

SPECIFICATIONS:
MODEL: S400 / S400S058 / S400-110H58U-AHM/1.32 96TM1
CONDITION: NEW
TYPE: TURBOCHARGER
TECHNOLOGY: TWIN HYDRODYNAMIC JOURNAL BEARINGS, EXTENDED TIP TECHNOLOGY COMPRESSOR WHEEL, TWIN-SCROLL TURBINE HOUSING
COMPRESSOR WHEEL INDUCER DIAMETER: 80 MM (3.16 IN)
COMPRESSOR WHEEL EXDUCER DIAMETER: 109.73 MM (4.32 IN)
TURBINE WHEEL INDUCER DIAMETER: 95.7 MM (3.77 IN)
TURBINE WHEEL EXDUCER DIAMETER: 88.05 MM (3.47 IN)
TURBINE HOUSING A/R: 1.32
TURBINE HOUSING INLET FLANGE: T6 TWIN FLOW
COOLING: OIL COOLED
HORSEPOWER RANGE: 750-1250 HP
ENGINE / EQUIPMENT FITMENT: JOHN DEERE 6125, 6125H

REPLACES:
OEM: JOHN DEERE
OEM INTERCHANGE PART NUMBERS: 171558 175252 177287 477287 RE506333 RE507021 RE508022 RE525341

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.

- 2001-2011 JOHN DEERE AGRICULTURAL & INDUSTRIAL EQUIPMENT WITH 6125 ENGINE
- 2001-2011 DEUTZ INDUSTRIAL EQUIPMENT WITH 6125H ENGINE
- 2001-2011 DEUTZ S650 TRACTOR WITH 6125H ENGINE
- JOHN DEERE 7500, 7700, & 7800 FORAGE HARVESTERS (SELF-PROPELLED)
