3-Petal Reed Valve Compatible With Suzuki Dt40 40Hp 696Cc Dt30 30Hp 499Cc 2-Cylinder 2-Stroke

OEM PART NUMBERS:
• Suzuki: 13150-94400 / 1315094400 (DT40 Reed Valve Assy - Original)
• Suzuki: 13150-94401 / 1315094401 (DT40 Reed Valve Assy - Superseded)
• Suzuki: 13150-94402 / 1315094402 (DT40 Reed Valve Assy - Current)
• Suzuki: 13150-91L00 / 1315091L00 (DT30/DT25K Reed Valve Assy)

SPECIFICATIONS:
• Type: 3-Petal Reed Valve Assembly
• DT40 Engine: 2-Cylinder 696cc, Bore 79mm (3.11"), Stroke 71mm (2.80")
• DT30 Engine: 2-Cylinder 499cc, Bore 71mm (2.80"), Stroke 63mm (2.48")
• Induction: Loop-Charged, Single Carburetor
• Ignition: Suzuki PEI (Pointless Electronic Ignition)
• Reed Configuration: 3-Petal
• HP Range: 30HP - 40HP
• Condition: New

SUZUKI DT30 & DT40 APPLICATIONS:
• DT40 / DT40C / DT40W / DT40WR 40HP 696cc 2-Cyl (1984-1998)
• DT40TC 40HP 696cc Trim/Tilt (1994-1998)
• DT30 / DT30R 30HP 499cc 2-Cyl (1983-2017)
• DT30C 30HP 499cc Oil-Injected (1988-2000)PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
SUZUKI DT40 40HP (696cc, 2-CYLINDER, 79mm x 71mm BORE x STROKE):
• DT40 40HP 2-Cyl 696cc Loop-Charged 2-Stroke (1984-1998)
• DT40C 40HP 2-Cyl 696cc Oil-Injected 2-Stroke (1985-1998)
• DT40W 40HP 2-Cyl 696cc PEI Ignition 2-Stroke (1985-1998)
• DT40WR 40HP 2-Cyl 696cc Remote Control 2-Stroke (1985-1998)
• DT40TC 40HP 2-Cyl 696cc Trim/Tilt 2-Stroke (1994-1998)

SUZUKI DT30 30HP (499cc, 2-CYLINDER, 71mm x 63mm BORE x STROKE):
• DT30 30HP 2-Cyl 499cc Loop-Charged 2-Stroke (1983-2017)
• DT30C 30HP 2-Cyl 499cc Oil-Injected 2-Stroke (1988-2000)
• DT30R 30HP 2-Cyl 499cc Remote Control 2-Stroke (1983-2017)

ENGINE SPECIFICATIONS:
• DT40: 2-Cylinder, 696cc, Bore 79mm (3.11"), Stroke 71mm (2.80"), PEI Ignition
• DT30: 2-Cylinder, 499cc, Bore 71mm (2.80"), Stroke 63mm (2.48"), PEI Ignition
• Both: Loop-Charged, Single Carburetor, 2-Stroke
• Reed Configuration: 3-Petal

NOTE:
• Verify OEM reed valve part number before ordering
• DT40 uses 13150-94400/94401/94402
• DT30 uses 13150-91L00
