12V Motor Reversing Solenoid Switch Compatible With Cole Hersee 24450 24450Bx Trombetta 214-1211A11

COLE HERSEE PART NUMBERS:
• 24450 - Motor Reversing Solenoid
• 24450BX - Motor Reversing Solenoid
• 24450-BX - Motor Reversing Solenoid
• CH24450 - Cole Hersee OEM
• 24450-02B - 24V Version (different voltage)

TROMBETTA PART NUMBERS:
• 214-1211A11 - Primary Part Number
• 214-1211A11-06 - Revision
• 214-1211A51 - Cross-Reference
• 214-1211A61 - Cross-Reference
• 214-1211A61-06 - Revision
• 214-1231A11 - Cross-Reference
• 214-1231-A11 - Alternate Format
• 214-1231A61-06 - Revision
• 2141211A11 - Without Dashes
• 2141211A1106 - Without Dashes
• 2141211A51 - Without Dashes
• 2141211A61 - Without Dashes
• 2141211A6106 - Without Dashes
• 2141231A11 - Without Dashes

EMS PART NUMBERS:
• 31-8970 - EMS Cross-Reference
• 318970 - Without Dash

REXCO PART NUMBERS:
• 7-1205 - Rexco Cross-Reference
• 71205 - Without Dash

PIC / PICTURE ID:
• 6660-110 - Picture ID Reference

SPECIFICATIONS:
• Voltage: 12V DC
• Type: DPDT Motor Reversing Solenoid
• Surge Current: 150A Inrush
• Continuous: 75A (5-Minute Carry)
• Terminals: 6 Total
• Studs: (4) 5/16"-24 Threaded (Battery & Motor)
• Blade Terminals: (2) 6.4mm (1/4") for Solenoid Operation
• Mounting: Flat 180 (F180)
• Duty Cycle: Intermittent
• Case Material: ABS Plastic
• Contact Material: Copper-CadmiumPRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.WARNING - This product may expose you to chemicals such as Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
WINCH APPLICATIONS:
• Truck Winches - Off-Road Recovery
• ATV/UTV Winches - Recreational Vehicles
• Trailer Winches - Boat, Utility, Car Hauler
• Industrial Winches - Construction, Warehouse
• Late Model Ramsey Winches
• Late Model Warn Winches

MARINE APPLICATIONS:
• Windlass Motors - Anchor Systems
• Boat Lifts - PWC, Pontoon, Boat Dock
• Sea Legs Systems - Sea-102
• Boat Trailer Winches
• Marine Hydraulic Pumps

RV & CAMPER APPLICATIONS:
• RV Slide Outs - Motor Home, Fifth Wheel
• RV Leveling Systems - Jacks, Stabilizers
• Camper Slide Outs - Travel Trailer
• Motor Home Accessories

SNOW PLOW & SPREADER APPLICATIONS:
• Snow Plow Motors - Lift, Angle
• Salt Spreader Motors
• Sand Spreader Motors

TRUCK & COMMERCIAL APPLICATIONS:
• Tarp Systems - Dump Truck, Grain Truck, Flatbed
• Hydraulic Pump Motors
• Hoists - Lift, Crane, Material Handling
• Linear Actuators

COMPATIBLE MOTOR TYPES:
• Permanent Magnet DC Motors (2 Terminal)
• Reversible Motors Requiring Multiple Solenoids
• Motors with Forward/Reverse Operation

OPERATING PARAMETERS:
• 75 Amp: Maximum 5 Minutes On Time
• 125 Amp: Maximum 30 Seconds On Time
• 150 Amp: Maximum 0.5 Seconds On Time
• Allow 5 Minute Cool Down After Maximum Use
